Four wheel drive Bulletproof off-road vehicle is based on customer needs. The car uses the Cummins 200 horsepower four engines, A121 manual five gear Gearbox, 37*12.5R16.5TL off-road tyre; the front and rear bridges have differentials, shock-reducing driver seats with air conditioners. Add the box behind the original double-row cab. The car is equipped with a folding seat, which can carry the off -road Warrior that can be carried and manned. At the same time Connect with each other. The body uses a 32mm bulletproof steef plate, a 35mm thick bulletproof glass, and the top is equipped with a weapon to the table, tyre can also be equipped with bullet-proof off-road tires. Coupled with the original high-engine and off-road nature, it is free to come and go like galloping cheetahs on the battlefield.
Detailed Specification
| Basic Technical Condition | |
| Engine | ISDE200 41 |
| Gearbox | Mechanical gear, six forward blocking |
| Transfer Case | Four rounds of full-time drivei; high and low |
| Front Bridge | 2.9 tons |
| Middle Axle/Rear Axle | 3.5 tons |
| Tyre | 305/80R18MPT |
| Electrical Appliance | 24V circuit system |
| Basic Parameters | ||
| Size Parameters | Overall Dimensions (length x width x height) (mm) | 4950 x 2375 x 1860 |
| Wheel Base (mm) | 3300 | |
| Approach Angle/ departure Angle (°) | 56/40 | |
| Quality Parameters | Follow Weight (kg) | 4900 |
| Load Quality (kg) | 1400 | |
| Total Mass (kg) | 6300 | |
| Maximum Power (kW) | 134 | |
| Displacement (ML) | 4500 | |
| MAX. Torque (n.m) | 560 | |
| Maximum Speed (km / h) | 120 | |
| Performance Parameters | Max.Gradeability (%) | 60 |
| Minimum Ground Clearence (mm) | 400 | |
| Minimum Taring Radius (m) | >8.5 | |
| Maximum Vertical Crossing Obstacle Height (mm) | 450 | |
| 100 km Fuel Consumption (L) | 19 | |
| Fuel Tank Capacity | 50 + 56 | |
